也叫扭力板子或力矩板子，力矩便是力和距離的乘積，在緊固螺絲螺栓螺母等羅紋緊固件時需求操控施加的力矩巨細，以保證羅紋緊固且不至于因力矩過大破壞羅紋，所以用扭矩板子來操作。首要設定好一個需求的扭矩值出色，當施加的扭矩抵達設定值時，板子會拍發"卡塔"動靜或者板子連接處折彎一點兒角度，這就代表已緊固不要再加力了。
Also known as a torque plate or torque plate, torque is the product of force and distance. When tightening ribbed fasteners such as screws, bolts, and nuts, it is necessary to control the magnitude of the applied torque to ensure that the ribs are tightened and not damaged due to excessive torque. Therefore, a torque plate is used for operation. Firstly, set the maximum torque value required. When the applied torque reaches the set value, the board will emit "chatter" or bend a little angle at the connection of the board, indicating that it has been tightened and no more force should be applied.
具有預設扭矩數據和動靜安裝。當緊固件的擰緊扭矩抵達預設數據時，能自動拍發信號"卡嗒"（click）的一聲，一同伴有明顯的手撫摸時的感覺振蕩，提示結束作業。免除效用力后，板子各相關零件能自動復位。
Equipped with preset torque data and dynamic and static installation. When the tightening torque of the fastener reaches the preset data, it can automatically send a signal of "click", accompanied by a noticeable oscillation of hand touch, indicating the end of the operation. After eliminating effective force, all relevant parts of the board can automatically reset.
二可切換二種方向。撥轉棘輪轉向開關，板子可逆時針加力。
Two directions can be switched. Turn the ratchet steering switch and apply force to the board in a reversible clockwise direction.
公英制（N.mlbf.ft）雙刻度線；手柄微分刻度線。讀數明晰準確。
Metric English (N.mlbf.ft) double scale mark; Handle differential scale mark. The reading is clear and accurate.
硼鋼資料鍛制，堅忍經用，生計的年限長 。校準追溯至西方強國國家技術標準學會（NBS）。
Made of boron steel materials, it is durable and has a long lifespan. Calibration can be traced back to the Technical Standards Society (NBS) of Western countries.
準確度符合 ISO 6789：1992. ASME B107.14 , GGG - W-68.
Accuracy in accordance with ISO 6789:1992 ASME B107.14 , GGG - W-68.
按照工件所需扭矩值要求，確定預設扭矩值。
Determine the preset torque value according to the required torque value requirements of the workpiece.
二預設扭矩值時，將板子手柄上的確定環下拉，一同轉動手柄，調度標尺主刻度線和微分刻度線數據至所需扭矩值。調度好后，松開確定環，手柄自動確定。
When setting two preset torque values, pull down the determining ring on the board handle and rotate the handle together to schedule the data of the main and differential scale lines of the scale to the desired torque value. After scheduling, release the confirmation ring and the handle will automatically confirm.
在板子方榫上裝上響應標準套筒，并套住緊固件，再在手柄上緩慢用力。施加外力時建議按標明的箭頭方向。當擰緊到拍發信號"卡嗒"（click）的一聲（已抵達預設扭矩值），間斷加力。一次作業結束。
Install a response standard sleeve on the square tenon of the board, cover the fastener, and then slowly apply force on the handle. When applying external force, it is necessary to follow the indicated arrow direction. When the torque is tightened to a signal of "click" (reaching the preset torque value), the force is applied intermittently. End of one assignment.
大標準扭矩板子使用時，可外加接長套桿以便操作省力。
When using a large standard torque board, an extension sleeve rod can be added for labor-saving operation.
如長時間不必，調度標尺刻線退至扭矩更小數據處。
If it is not necessary for a long time, adjust the scale line back to the minimum torque data point.
1訂做要求：付款方式：先付30%的訂
1. Customization requirements: Payment method: 30% of the order must be paid in advance
2出貨前付清剩余70%的余款
2. Pay the remaining 70% before shipment
3我們是不收取樣板費
We do not charge sample fees
4訂做時間為：收到30%的訂后7天貨期
4. Customization time: 7 days after receiving 30% of the order
5如有疑問請在線客服.
If you have any questions, please contact online customer service
